Ferrari GTO Specifications
|
|
Body style
|
. . . . . . . . . . . .
|
Coupe, two passenger, two door
|
|
Body material
|
. . . . . . . . . . . .
|
21 gauge aluminum
|
|
Chassis
|
. . . . . . . . . . . .
|
Tubular steel, space frame
|
|
Weight
|
. . . . . . . . . . . .
|
2474 lbs. (1124.5 kilograms)
|
|
Price (1964)
|
. . . . . . . . . . . .
|
Approximately $23,000
|
|
Wheelbase
|
. . . . . . . . . . . .
|
94.5 inches (2400 mm.)
|
|
Brakes, Front
|
. . . . . . . . . . . .
|
Cast iron discs, 12.4 inches (314 mm.)
|
|
Brakes, Rear
|
. . . . . . . . . . . .
|
Cast iron discs, 11.8 inches (298 mm.)
|
|
Fuel Capacity
|
. . . . . . . . . . . .
|
35.1 gallons
|
|
Front Track
|
. . . . . . . . . . . .
|
53.1 inches (1351 mm.)
56.8 inches (1445 mm.)
|
|
Rear Track
|
. . . . . . . . . . . .
|
53 inches (1346 mm.)
55.7 inches (1346 mm.)
|
|
Length
|
. . . . . . . . . . . .
|
173.1 inches (4400 mm.)
169.2 inches (4300 mm.)
|
|
Width
|
. . . . . . . . . . . .
|
65.9 inches(1675 mm.)
69.2 inches (1760 mm.)
|
|
Height
|
. . . . . . . . . . . .
|
49.0 inches (1245 mm.)
44.9 inches (1140 mm.)
|
|
Note: Colored text denotes 1964 (series 2) models
|
|
|
|
|
Engine
|
|
Configuration
|
. . . . . . . . . . . .
|
60° V12, Single chain
driven overhead cam
per head
|
|
Displacement
|
. . . . . . . . . . . .
|
2953.211 cc. (180 cubic inches)
|
|
Bore / Stroke
|
. . . . . . . . . . . .
|
73.0 mm. / 58.8 mm.
|
|
Compression Ratio
|
. . . . . . . . . . . .
|
9.7:1
|
|
Output
|
. . . . . . . . . . . .
|
300 bhp @ 7500 rpm
|
|
Torque
|
. . . . . . . . . . . .
|
295 lbs-ft. @ 7000 rpm
|
|
Redline
|
. . . . . . . . . . . .
|
8000 RPM
|
|
Oil Capacity
|
. . . . . . . . . . . .
|
21.1 Quarts
|
|
|
Suspension
|
|
Front
|
. . . . . . . . . . . .
|
Independent,
Unequal length A-arms,
Coil over Koni Shocks
|
|
Rear
|
. . . . . . . . . . . .
|
Live axle,
semi-elliptic leaf springs,
trailing arms,
coil springs over Koni Shocks,
anti-sway bar
|
|
Steering
|
. . . . . . . . . . . .
|
ZF Worm and Peg
|
|
Steering ratio
|
. . . . . . . . . . . .
|
17:1
|
|
|
Transmission
|
|
Type
|
. . . . . . . . . . . .
|
Five speed manual
|
|
First Gear
|
. . . . . . . . . . . .
|
2.935:1
|
|
Second Gear
|
. . . . . . . . . . . .
|
1.975:1
|
|
Third Gear
|
. . . . . . . . . . . .
|
1.45:1
|
|
Fourth Gear
|
. . . . . . . . . . . .
|
1.17:1
|
|
Fifth Gear
|
. . . . . . . . . . . .
|
1:1
|
|
Reverse
|
. . . . . . . . . . . .
|
3.478:1
|
|
Differential
|
. . . . . . . . . . . .
|
ZF Limited Slip
|
|
|
|
|
Performance
|
|
0 to 30 mph
|
. . . . . . . . . . . .
|
2.5 seconds*
|
|
0 to 40 mph
|
. . . . . . . . . . . .
|
3.9 seconds*
|
|
0 to 50 mph
|
. . . . . . . . . . . .
|
4.9 seconds*
|
|
0 to 60 mph
|
. . . . . . . . . . . .
|
5.8 seconds*
4.7 seconds**
|
|
0 to 70 mph
|
. . . . . . . . . . . .
|
7.6 seconds*
|
|
0 to 80 mph
|
. . . . . . . . . . . .
|
9.0 seconds*
7.4 seconds**
|
|
0 to 90 mph
|
. . . . . . . . . . . .
|
10.9 seconds*
|
|
0 to 100 mph
|
. . . . . . . . . . . .
|
12.7 seconds*
10.5 seconds**
|
|
0 to 110 mph
|
. . . . . . . . . . . .
|
14.8 seconds*
|
Standing
1/4 mile
|
. . . . . . . . . . . .
|
14.4 seconds @ 108 mph*
13.1 seconds @ 113 mph**
|
|
Top Speed
|
. . . . . . . . . . . .
|
144 mph*
|
Braking,
70 to 0 mph
|
. . . . . . . . . . . .
|
218 feet*
|
Braking,
60 to 0 mph
|
. . . . . . . . . . . .
|
112 feet**
|
*Car and Driver, April 1984. s/n 5571 GT
**Road and Track, June 1997. s/n 3943 GT.
|
|
Some notes about the top speed rating: The 144 mph we've quoted is the only documented measured top speed for a Ferrari GTO that we've been able to find. GTO drivers at Le Mans would see 7,500 RPM on long stretches which, according to the gear charts, works out to 175 mph.
|
